1778638
Manufacturer:
Phoenix Contact
Mfr.Part #:
1778638
Datasheet:
Description:
Terminal Blocks Through Hole 3 2.5 mm 6 A 150 V
| Parameter | Value |
|---|---|
| Length | 7.5 mm |
| Width | 9.2 mm |
| Termination | Solder |
| Number of Pins | 3 |
| Height | 5 mm |
| Packaging | Reel |
| Voltage Rating | 150 V |
| Depth | 7.5 mm |
| Lead Free | Lead Free |
| RoHS | Compliant |
| Voltage | 150 V |
| Contact Plating | Tin |
| Contact Material(Contact Finish) | Tin |
| Pitch | 2.5 mm |
| Current | 6 A |
| Current Rating | 6 A |
| Max Current Rating | 6 A |
| Flammability Rating | UL94 V-0 |
| Approvals | UL |
| Orientation | Right Angle |
| Color | Black |
| Number of Poles | 3 |
| Connector Type | Plug |
| Number of Positions | 3 |
| Number of Rows | 1 |
| Housing Material | Polymer |
| Number of Positions Per Level | 3 |
| Number of Levels | 1 |
| Housing Color | Black |
| Connection Method | Plug |
Stock: 596
Distributors
pcbx
pcbxUnit Price$0.75274
Ext.Price$0.75274
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $0.75274 | $0.75274 |
| 10 | $0.61152 | $6.11520 |
| 25 | $0.56160 | $14.04000 |
| 50 | $0.51575 | $25.78750 |
| 100 | $0.47365 | $47.36500 |
| 300 | $0.45191 | $135.57300 |
| 500 | $0.43117 | $215.58500 |
| 1000 | $0.40992 | $409.92000 |
